Engine model KTA38-G2A
Engine type 12 Cylinders, V Type
Displacement 37.8 L
Rated Power (KW@RPM) 813 kW(1090HP)@ 1500rpm
Standby Power (KW@RPM) 895 kW(1200HP)@ 1500rpm
Governing Rate: ≤5%
Cummins diesel engine KTA38-G2A Technique Specification
Bore*stroke 159 mm* 159mm
Intake method Turbocharged& Intercooled
Fuel systeme PT Pump Direct Injection
Cooling method Fluid Cooling
Governor Type Mechanical Control
Fuel Consumption @ Rated Power 225L/hr
Fuel Consumption @ Standby Power 247L/hr
Idel Speed 575-650r/min
Starting System Electrical Starting Motor 12V/24V
Lowest Starting Temp .(without auxiliary system) -12℃
Cummins diesel engine KTA38-G2A Trade Information
Warranty time 1year or 1500h
Engine Size(L*W*H): 2341mm*1360mm*1653mm
Weight net 3850 Kg
Delivary port Shanghai
Delivary time 15 working days
Trade termes FOB/CIF/CNP
Payement termes T/T，L/C
All the spare parts for Cummins KTA38-G2A are available;显示更多
Jining Haoduo Import and export co., Ltd.
Second floor, First section, No.2 building,Jining Lantian Boiler 272000 Jining 济宁 Shandong 山东 中国
