BF4L913 DIESEL ENGINE TECHNICAL DATASHEET
MODEL OF DIESEL ENGINE BF4L913
NUMBER OF CYLINDER 4
NUMBER OF STROKE 4
COOLING WAY AIR-COOLED
RATED POWER (KW/RPM)
47/1500
55/1800
66/2300
78/2500
CHAMBER TYPE DIRECT INJECTION
BORE/STROKE(mm) 102/125
DISPLACEMENT(L) 4.086
AUTOMOTIVE POWER
AS PER DIN70020 (kW(PH)/r/min) 78(106)/2500
ISO 3046/(IFN )NET
BRAKE FUEL STOP POWER
(kW(ps)/r/min) MAX POWER HIGHLY INTERMITTENT 78(106)/2500
MAX POWER INTERMITTENT 72(98)/2500
ISO STANDARD FUEL STOP POWER (ICFN) kW(PH)/r/min MAX 66(90)/2300
kW(PH)/r/min MIN 47(64)/1500
MAX.YORQUE AS PER DIN70020 (N.m/r/min) 342/16500
NET WEIGHT(kg) 350
DIESEL ENGINE SUPPORT SPACE(Dmm) 575
TYPE OF STANDARD FLYWHEEL CASING(SAE) 2+3+4
STARTING WAY ELECTRIC
LUBRICATING WAY PRESSURE LUBRICATION
ROTATION DIRECTION COUNTER-CLOCKWISE
NET DIMENSION(L×W×H)(mm) 725×665×800显示更多
