丰田 7 FB 25

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours,24 hours, holidays and Sundays Address: Shanghai City, China Contact: Jason Whatsapp: +86 13675656717 Mobile:+86 13675656717 Wechat:13675656717 Email: Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.

Basic parameters Rated lifting capacity: 2500kg Load center distance: 500mm Type of power: Electricity Self-weight: Approximately 3,980 kg or 4,200 kg Dimensional parameters Total length (excluding forks) : approximately 2700mm Full width: approximately 1250mm The height of the roof guard frame is approximately 2150mm Fork length: 1200mm Minimum turning radius: approximately 2200mm Performance parameters Maximum lifting height: The standard mast height is 3000mm, and a higher mast height can be optionally equipped Maximum lifting speed: approximately 4m/min Maximum driving speed: 26km/h Climb: Approximately 18% Braking distance: ≤2.5m Electrical system parameters Battery voltage: 48V Battery capacity: Available in multiple options such as 48V/560Ah Charger power: approximately 5kW Other parameters Tire type: Solid tire Gantry form: Two-section gantry, and an optional gantry with a side shifter Operation mode: Sitting operation
