柳工 CLG 856 H

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours,24 hours, holidays and Sundays Address: Shanghai City, China Contact: Jason Whatsapp: +86 13675656717 Mobile:+86 13675656717 Wechat:13675656717 Email: Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.

Basic performance parameters Rated load capacity: 5000kg The overall operating weight of the machine is 16,900 kg Bucket capacity: 2.7-5.6m³ (Standard bucket capacity is 3m³) Maximum digging force (lifting force) : 175kN Maximum traction force: 175kN Power type: Fuel Walking mode: Tire type Working condition application: General type Tonnage range: 5 to 8 tons Engine parameters Engine model: Cummins QSL9.3 Type: Electronic fuel injection, six-cylinder in-line, turbocharged air-cooled Rated power/speed: 168kW/2200rpm Maximum torque/speed: 1187N·m/r/min Total displacement: 9.3L Fuel consumption rate: The specific value may vary depending on the operating conditions Overall machine size parameters Overall length: 8230mm Overall width: 2970mm Overall height: 3500mm Wheelbase: 3320mm Track: 2150mm Minimum ground clearance: 431mm Job parameters Unloading height - unloading Angle: 45° : 3100mm Unloading distance - Unloading Angle of 45° : 1195mm Total of three items (working device action time) : 10.3 seconds Boom lifting time: 5.8 seconds Steering Angle: 38° Minimum turning radius (calculated from the center of the outer wheel) : 5905mm Transmission: The driving speed has multiple adjustable gears. For example, the forward/reverse speed in first gear is 11.5/15km/h, and in second gear it is 37km/h. Fuel capacity: The fuel tank capacity is 300L, engine oil is 22L, and the cooling system capacity is 42L
