柳工 CLG 856 H

856H DESIGNED TO WORK HARDER, FOR LONGER 856H - STAGE V Maximum operating weight 22502kg Minimum operating weight 19870kg Standard bucket 3.0 m³ Gross power 183 kW (245 hp) @ 2000 rpm Net power 168 kW (225 hp) @ 2000 rpm Rated load 5000 kg Total cycle time 9.3 s Tipping load-full turn 11700 kg Bucket breakout force 187 kN Dump clearance, full height discharge 3084 mm Dump reach, full height discharge 1125 mm Model Cummins 6LT9.3 Emissions EU Stage V Cooling system Charge air cooling Length with bucket down 8318 mm Width over tires 2750 mm Cab height 3450 mm Turning radius, outside of tire 6.205 mm Bucket capacity 2.6 – 5.6 m³ General Purpose 3.0 m³ Light material 4.2, 5.2, 5.6 m³ Heavy-rock 2.7 m³
