杰西博 3 CX

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours,24 hours, holidays and Sundays Address: Shanghai City, China Contact: Nina Whatsapp: +86 18055199047 Mobile:+86 18055199047 Wechat:18055199047 Email: Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs

Engine: Model is JCB 3CX, with a rated power of 63kW/2200rpm and a maximum torque of 320Nm/1200rpm. It has a displacement of 4.4L, a cooling system configured for hot climates, a pre-pressurized suction fan, a pre-pressurized backup water tank, and features natural aspiration. Overall Dimensions: Total length in driving state is 5620mm, total width is 2360mm, total height is 3610mm, cab top height is 2870mm, steering wheel center height is 1940mm, and wheelbase is 2170mm. Operating Weight: 7370kg. Hydraulic System: The main pump is a gear pump, with a maximum system flow of 73+51L/min and a system working pressure of 251bar. Transmission: Transmission model is JCB 3CX, with a torque converter diameter of 305mm and a torque ratio of 3. The travel speeds are: 5.5/5.6km/hr (1st gear forward/backward), 8.9/9.0km/hr (2nd gear), 19.1/19.2km/hr (3rd gear), and 34.8/34.8km/hr (4th gear). Tire Size: Front tires 12.5×18, rear tires 18.4×26. Fluid Capacities: Fuel tank 160L, hydraulic system including tank 132L, transmission including filter 16L, engine oil and filter 15L, cooling system 18.5L, front axle 16L, rear axle 16L. Loader End Performance: Optional loader bucket types include general-purpose loader buckets and 6-in-1 loader buckets. The bucket capacities are 1.0m³ (general-purpose bucket) and 1.1m³ (6-in-1 bucket) respectively. The maximum dump height is 2740mm (general-purpose bucket)/2720mm (6-in-1 bucket), and the maximum dump reach is 830mm (general-purpose bucket)/780mm (6-in-1 bucket). Excavator End Performance (Standard Excavator Arm): Excavator bucket types include standard-section buckets and deep-section buckets, with capacities ranging from 0.06-0.3m³ (standard-section buckets) and 0.09-0.48m³ (deep-section buckets) respectively. The maximum digging depth is 4240mm (retracted position)/5460mm (extended position). The maximum working height of the excavator bucket is 5530mm (retracted position)/6350mm (extended position), and the maximum dump height of the excavator bucket is 3840mm (retracted position)/4720mm (extended position).
