捷尔杰 ET500J

Performance Platform Height 50-ft .5-in / 15.2-m Horizontal Outreach 31-ft 6-in / 9.6-m Centerline to Platform Edge 31-ft / 9.45-m Swing 410 Degrees Non-Continuous Platform Capacity 500-lb / 227-kg Platform Capacity w/Rotator (Optional) 440-lb / 200-kg Material Hook Capacity 500-lb / 227-kg Platform Rotator 90 Degrees Manual Jib Length 4-ft / 1.22-m Jib Vertical Motion 130 Degrees (+75, -55) Weight* 5,200-lb / 2,177-kg Leveling Capability 11 Degrees Max. Ground Bearing Pressure 31 psi / 2.18 kg/cm² Towing Speed Rating 65 mph / 105 km/h Tongue Weight* 450-lb / 204-kg Max Gradability 20% Hydraulic Reservoir 6.0 gal / 22.71 L *Certain options or country standards increase weight Power Source DC Power 24V DC Batteries 4 x 6V 220 amp-hr Tires Standard ST225/75 R15 Pneumatic
