三一重工 SCC 1800

Fly Jib ,Hook ,Counter Weight, ETC. We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours:24 hours, holidays and Sundays Contact: Jason Whatsapp: +86 13675656717 Mobile:+86 13675656717 Wechat:13675656717 Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.

Lifting performance parameters Maximum rated lifting capacity: 180 tons Maximum main arm length: 82 meters Maximum lifting moment: 1056t·m Main arm luffing Angle: 30-80° Speed parameter Maximum single-rope speed of the hoist: 130m/min Maximum rotational speed: 1.3r/min Maximum walking speed: 1km/h Size parameters Total transportation length: 17,500mm Transportation full width: 3000mm Total height for transportation: 3250mm Track plate width: 1100mm Weight parameter Maximum single piece transportation weight: 45 tons Rear counterweight weight: 68 tons Grounding specific pressure: 0.118MPa Power parameters Engine model: Dongfeng Cummins QSL8.9-C325 Maximum engine power: 242kW/2100rpm Maximum engine torque: 1385N·m/1500rpm
