Mini crane on a crawler chassis TB5000
A mini crane on a crawler chassis designed for indoor and outdoor work. Maximum capacity: 2400 kg.
Completely Polish product.
It can be transported on a trailer with a GVW of 3.5 T.
* radio control of the device - driving, working, spreading your feet
*double crane power supply - diesel and electric 230 V
*maximum lifting capacity - 2400 kg
*anti-overload system as standard
*maximum horizontal range over 11 m
*four hydraulic extensions + 1 manual extension
*maximum vertical range over 12 m
*4 supports lowered hydraulically
*weight approx. 2200 kg
*height about 195 cm
*width approx. 88 cm
* active arm 16 degrees
Possibility of retrofitting the set with any vacuum cup of the XP and XR series and a hydraulic winch.
Feel free to contact us显示更多
