曼尼通 MT 1740 SL T
不含税价格
打印
信息
类别
伸缩臂叉装车|叉装车
品牌/型号
曼尼通 MT 1740 SL T
生产年份
2020
使用小时
2500 小时
国家
中国
一般等级
1
2
3
4
5
马斯客 ID
BE4D0BF3
定价
选择币种
详细信息
内部库存编号
1
电源类型
柴油机
类型
旋转
生产号/编号
1
牵引类型
4x4
最新检验记录
2025-07-08
先前车主有几个
1
毛重
11200 公斤
最大起重能力
4000 公斤
注册编号
1
最大举升高度
16.7 m
车厢类型
封闭式驾驶室
排放标准
第V阶段
发动机
Original
车型
固定构件
发动机输出功率
74.5 kW (101 马力)
发动机制造商
Original
变速器
Original
发动机排量
4400 cm3
最大速度
25 千米/小时
轮胎尺寸
400/80-24 TL 156B
原色
Original
辅助液压设备的输出量
196 l/min
运输尺寸(长x宽x高)
7180 x 2425 x 2785 mm
轮胎品牌
米其林
达到最大负荷
12.4 m
状态/质保
Good Condition
剩余前轮/车盘
98
后轮胎折旧程度
2
制造国
法国
成交条件
FCA, FOB, CIF, EXW
证书
EPA环境保护署, CE认证
附属装置
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL
Business hours,24 hours, holidays and Sundays
Address: Shanghai City, China
Contact: Jason
Whatsapp: +86 13675656717
Mobile:+86 13675656717
Wechat:13675656717
Packaging Details
1. Flat frame is more suitable for large construction equipment without disassembly.
2. Containers are the cheapest and fastest.
3. Bulk carriers are more suitable for large construction equipment.
4. Ro-ro shipment is fast and suitable for all kinds of machines.
You can choose any mode of transportation according to your needs.
配件
叉子
稳定器
附加液压设备
铲斗
其他信息
Basic performance
Engine power (kW)74.5/2200
Operating weight (in kilograms) : 11,220
Rated load (kg) : 4000
More than 100 horsepower
The maximum load (in kilograms) is over 3,500 kilograms
Job parameters
Maximum lifting capacity (kg) : 4000
The lifting Angle range is from the lowest to the highest (°)-0.028967254
Maximum lifting height (m) : 16.65
Maximum external elongation (m)12.35
The maximum external elongation overturning load (kg) is 957
Turning radius (m) : 5709
Engine
Model: Perkins 1104D-44T
Rated power (kw/rpm)74.5/2200
Maximum torque (N.m) : 412/1400
Displacement (L) : 4.4
Hydraulic system
The maximum working pressure of the system (bar) is 260
The maximum system flow rate (L/min) is 196
Transmission system
Gear 4
Maximum driving speed (km/h) : 25
Tire size: 440/80-24
Oil capacity
Fuel tank (L)135
Oil tank (L)11
Engine coolant (L)18.5
Transmission fluid (L)16
Hydraulic system (L)175
Overall dimensions
The total length of the entire machine is 7180 mm
The total length of the entire machine is 5980 mm
The full width of the entire machine (mm) is 2425
The total height of the entire machine (mm) is 2785
Cab height (mm) : 2605
The height of the steering wheel from the ground is 1880 mm
Wheelbase (mm) : 2770
Track (mm)1990
Ground clearance (mm) : 480
Departure Angle (°) : 50
