山特维克 D45KS

- 330 class under carriage, 15' 0" (4,57 m) long, 29.5" (750 mm) pads - 292 gallon (1105 l) fuel tank - Coolers for up to 130°F (54°C) ambient temperature - Rotary head speed 0-126 RPM, torque 87921 in-lb (9934 Nm) - Bullshaft with 3.5" API Reg Box thread - Loader inside mast, 30' (9,14 m) drill pipe, 4 1/2" - 7" (115 to 178 mm) OD - Heavy-duty pulldown chains - Three leveling jacks, 48" (1,2 m) stroke, 24" (610 mm) pads - Auxiliary winch 4000 lb (18 kN) capacity, 100' (30,5 m) cable - Two-man cab, air-conditioned, heated, - Service walkway cab side - Night lights, six 70 Watt - Color White - Air volume control for high-pressure compressor - Water injection 9 GPM 400-gallon tank (not with dust collector) - Heavy-duty head 5.5" API Box (recommended with 350 psi air) - Angle drilling 0°-30° in 5° increments with loader booster, - Extended mast, 36' (11 m) single pass, with standard loader - Auto tong group - Pipe thread greaser operated from inside cab - Air line lubricator, 30-gallon (114 L) reservoir - Central lube system, manual via central point - Fluids service center, fill, and evacuation - 24 Volt to 12 Volt converter - Feed pressure control override (recommended for 350 psi) - 50-hour maintenance kit - Parts, Service, Operator, and Engine Parts manuals (one each)
