山猫 s70

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours,24 hours, holidays and Sundays Address: Shanghai City, China Contact: Nina Whatsapp: +86 18055199047 Mobile:+86 18055199047 Wechat:18055199047 Email: Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs

Engine Parameters: Model: Kubota D1005-E3B-BC-3 Rated Power: 16.8kW / 3000rpm Maximum Torque: 62.8N·m / 2200rpm Displacement: 1.001L Number of Cylinders: 3 Performance Parameters: Rated Operating Capacity: 343kg Tipping Load: 686kg Operating Weight: 1268kg Maximum Travel Speed: 9.8km/h Hydraulic System Parameters: System Relief Pressure: 207bar Rated System Flow: 37L/min Dimension Parameters: Overall Length (without attachment): 1917mm Overall Length (with bucket): 2553mm Overall Width (tire edge): 901mm Overall Width (bucket edge): 914mm Overall Height (to cab top): 1814mm Wheelbase: 722mm Minimum Ground Clearance: 140mm Working Range Parameters: Maximum Dump Height: 1891mm Dump Reach (at maximum height): 469mm Maximum Height of Bucket Hinge Pin: 2399mm Dump Angle at Maximum Dump Height: 34° Bucket Rollback Angle at Maximum Height: 97° Bucket Rollback Angle on Ground: 22°
