Technical features:
Weight kg 4500
Dimensions closed machine with lifted column: Length 2.100 mm Width 2350 mm Height 2670 mm (without pole slide)
Movements hydraulic 1. Hammer starter stroke
2. Up/down movement of the hammer trolley 3. In/out movement of the slide stroke 600 mm
4. Stroke translator 130+130 mm
5. Column inclination from +10° to -51°
6. Slide inclination (training) from + 9,5° to -9,5°
7. Down/up movement of the column stroke 500 mm 8. Left track control
9. Right track control
Power Oil sets on the machine 180 BAR
Hydraulic system to open cicuit
Hydraulic pump at gear
Capacity oil tank 140 LT
Translation's speed of machine 1,92 3,33 KM/H
Engagement in HP 47,3
Maximum highest post 4.400 mm (6000 mm optional)
HAMMER
Impact power 950/1200 JOULE
Impact rate 620÷1.500/570÷1180
Weight 350kg/450 kg
Oil flow rate 60÷90 LT.-MIN./ 70÷100 LT.-MIN
Power oil sets on the hammer 170 BAR
ENGINE YANMAR 4TNV88:
n° cylinder 4
Swept volume 2.190 CM3
Power at 3.00显示更多
