Ormig 30 iE
不含税价格
向卖家询价
2
收藏
分享
保存搜索打印
信息
类别
其他起重机
品牌/型号
Ormig 30 iE
生产年份
2020
使用小时
1 小时
附加选项
未使用
国家
意大利
马斯客 ID
E5FA91F3
详细信息
内部库存编号
000187
成交条件
EXW
其他信息
Lifting capacity: at 1 m from front plate DIN 30t SAE 33t
Front drive
Electric motor: 2 da 15 kW
Hydraulic and services motor: 25 kW
Power source: 96 Volt 1240 Ah
Boom height: 12m
Working outreach: 8m
Road certification
Weight: 19 ton
BASE MACHINE composed of:
ORMIG frame - 4x2 traction.
N. 2 electric motors, for translation from about 15 kW, 96 V, with electronic control to allow steering on the machine axis.
Fixed front engine axle composed of two independent wheel groups with electronic differential - Steering rear axle
No. 4 cushion twin wheels on the front axle and n. 2 cushion wheels on the rear axle 854 320 600
Side-mounted driver's cab, closed, designed and built to allow the operator maximum visibility, digital instrumentation, anatomic and adjustable seat, control of hydraulic movements by means of multiple electronic lever with device against accidental operation, rear-view mirrors, windshield wipers
Hydraulic arm with three sections, extraction obtained through n. 2 double-acting hydraulic cylinders - double-acting hydraulic cylinder for lifting the arm.
Hydraulic winch with automatic brake, complete with rope, end stop and hook with block.
Electrical system approved for road circulation complete with headlights, rear lights and rotating lights.
Hydraulic system powered by a variable displacement pump, capacity 340 l, connected to the electric motor to c.a. from 25 kW
Lead acid accumulators, voltage 96V, capacity 1240A / h
Brakes in compliance with EEC standards, service brake with servo assisted pedal control, mechanical spring-applied parking brake acting on the front wheels with control via electric selector
Electronic anti-tipping device with locking of the functions that increase the danger situations according to the directives in force
Weight in transport position around 19.800 kg
Accessories.显示更多
