久保田 U 25

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours,24 hours, holidays and Sundays Address: Shanghai City, China Contact: Nina Whatsapp: +86 18055199047 Mobile:+86 18055199047 Wechat:18055199047 Email: Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs

Parameter Details Model Kubota D1105 - E3B Type 3 - cylinder, liquid - cooled, overhead valve diesel engine Displacement 68.5 cu in (1.123 L) Gross Power 20.9 hp (15.6 kW) @ 2,300 rpm Net Power About 20.7 - 21 hp (15.4 - 16 kW) Engine Oil Capacity 1.2 gal (4.5 L) Fuel Capacity 7.4 gal (28 L) Cooling System Fluid Capacity 1 gal (3.6 L) Hydraulic System Parameter Details Hydraulic Pump Type Triple pump Hydraulic Pump Capacity 23.8 + 14.2 + 11.3 L/min Auxiliary Hydraulic Flow 12.3 - 13 gpm (46.6 - 48 L/min) Maximum Hydraulic Pressure 2,623 psi (18.1 MPa) Maximum Bucket Breakout Force 4,990 lbf (22.2 kN) / 2,320 kgf Maximum Arm Breakout Force 2,994 lbf (13.3 kN) / 1,245 kgf Hydraulic System Fluid Capacity 5.8 gal (22 L) Performance & Operation Parameter Details Operating Weight 5,625 lbs (2,552 kg) Swing Speed 9.8 rpm Swing Design Zero tail swing Boom Swing Angle 75 degrees (left), 55 degrees (right) Travel Speed Low: 1.5 - 2.5 mph (2.4 - 4 km/h); High: 2.7 - 4.5 mph (4.3 - 7.2 km/h) Drawbar Pull 6,745 lbs (3,059 kg) / 30 kN Bucket Capacity 0.08 cubic meter Maximum Digging Depth 8 ft 4.8 in (2.56 m) Maximum Digging Height 15 ft (5 m) Maximum Reach Along Ground 14 ft 1.2 in (4.3 m) Dimensions Parameter Details Overall Length 4,150 mm (13.6 ft) Width to Outside of Tracks 1,498.6 mm (4.92 ft) Tail Swing Radius 2 ft 7 in (zero - tail swing design) Crawler Length 2,000 mm (6.56 ft) Ground Clearance 12 in (304.8 mm) / 284.5 mm Shoe Width 300 mm (12 in) Ground Pressure 3.32 - 3.4 psi (22.9 kPa / 0.23 kgf per cm²) Undercarriage & Drive Parameter Details Drive Motors Hydraulic axial piston motors with planetary final drives Tumbler Distance 1,560 mm Track Tension Needs monthly inspection as routine maintenance
