久保田 U 20

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours,24 hours, holidays and Sundays Address: Shanghai City, China Contact: Jason Whatsapp: +86 13675656717 Mobile:+86 13675656717 Wechat:13675656717 Email: Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.

Specification Power: Traditional power Manufacturer: Joint venture/Imported Bucket: Backhoe Tonnage :2 tons The working weight of the entire machine (kg) is 2,365 Bucket width (mm) : 450/400 Bucket capacity (m³) : 0.054 Performance Rotational speed (rpm) : 9.6 Walking speed (km/h) 2.1/4.0 Climbing ability (%) : 30° Bucket digging force (kN)18.4 Power system Engine model: D1105-E4 Rated power (kw/rpm) : 14/2200 Displacement (L)1.123 Hydraulic system Main pump types: variable pumps * 2+ gear pumps * 2 The rotary hydraulic motor type is cycloidal rotor motor The type of walking hydraulic motor is a 2-speed plunger hydraulic motor Oil capacity Fuel tank (L)28 Main body size The total length of transportation (mm) is 3850 The total transportation width (mm) is 1300/1500 The total transportation height (mm) is 2380 The total length of the track (mm) is 1860 Track plate width (mm) : 250 Minimum ground clearance (mm) : 170 The minimum turning radius (mm) of the front working device is 1850 Rear end turning radius (mm)710 Scope of work Maximum excavation radius (mm) : 4140 Maximum excavation depth (mm) : 2320 Maximum excavation height (mm) : 3880 Maximum unloading height (mm) : 2550 The maximum vertical excavation depth (mm) is 1900 The width × height (mm) of the bulldozer board is 130/1500 *292 The bulldozer shovel lifts or deepens (mm)340/270
