久保田 KX 161

# KUBOTA KX161 Crawler Excavator Specifications Model: KUBOTA KX161-3S Operating Weight: 5675 kg Bucket Capacity: 0.22 m³ Transport Dimensions (L×W×H): 5540 × 2110 × 2540 mm Track Shoe Width: 500 mm Travel Speed (High/Low): 4.6 / 2.6 km/h Swing Speed: 9.3 rpm Bucket Digging Force: 42.5 kN Arm Digging Force: 31.8 kN Max Digging Depth: 3830 mm Max Digging Radius: 6260 mm Max Dumping Height: 4155 mm Max Digging Height: 5715 mm Ground Clearance: 320 mm ## Engine Engine Model: Kubota V2403-M-E3 Rated Net Power: 34.3 kW / 2300 rpm Displacement: 2434 cc Fuel Tank Capacity: 70 L ## Hydraulic System Main Pump Max Flow: 132 L/min Max Working Pressure: 24.5 MPa
