久保田 KX 161

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours,24 hours, holidays and Sundays Address: Shanghai City, China Contact: Jason Whatsapp: +86 13675656717 Mobile:+86 13675656717 Wechat:13675656717 Email: Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.

Parameter configuration of Kubota KX161 excavator Specification The working weight of the entire machine (kg) is 5675 Bucket capacity (m³)0.22 Origin: Japan Tonnage (tons)6 Joint venture/import by manufacturers Power Traditional Power Bucket backhoe Joint venture/import by manufacturers Power Traditional Power Performance Rotational speed (rpm) : 9.3 Walking speed (km/h)2.5/4.6 Climbing ability (%)58/30 degrees Bucket digging force (kN)39 Power system Engine model: Kubota KUbota V2403-M Rated power (kw/rpm)34.6/2200 Displacement (L)2.434 The cooling method is water cooling Hydraulic system The main pump type is variable pump + gear pump The walking hydraulic motor type is a plunger hydraulic motor The rotary hydraulic motor type is a plunger hydraulic motor Is the hydraulic crushing pipeline a standard configuration Oil capacity Fuel tank (L)70 Main body size The total length of transportation (mm) is 5540 The total transportation width (mm) is 2110 The total transportation height (mm) is 2540 Track grounding length (mm)1990 The total length of the track (mm) is 2500 Track plate width (mm)550 The total width of the tracks (mm) is 2110 Track gauge (mm) : 1560 Minimum ground clearance (mm) : 320 The minimum turning radius (mm) of the front working device is 2420/1955 Rear end turning radius (mm) : 1090 Scope of work Maximum excavation radius (mm) : 6290 The maximum excavation radius (mm) of the shutdown face is 6165 Maximum excavation depth (mm) : 3860 Maximum excavation height (mm) : 5770 Maximum unloading height (mm) : 4125 The maximum vertical excavation depth (mm) is 2995 Boom rotation Angle (left/right °)50/80 The width × height (mm) of the bulldozer board is 2110×390 The bulldozer shovel lifts or deepens (mm)455/375
