久保田 KX 155

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours,24 hours, holidays and Sundays Address: Shanghai City, China Contact: Nina Whatsapp: +86 18055199047 Mobile:+86 18055199047 Wechat:18055199047 Email: Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs

Specifications Power Type: Traditional power Manufacturer: Joint venture/Imported Bucket Type: Backhoe Tonnage: 5 tons Operating Weight: 5190 kg Bucket Width: 730 / 680 mm Bucket Capacity: 0.16 m³ Performance Swing Speed: 9.3 rpm Travel Speed: 2.5 / 4.3 km/h Climbing Ability: 30° Bucket Digging Force: 36.5 kN Power System Engine Model: V2403-E3 Rated Power: 29.9 kW / 2250 rpm Displacement: 2.434 L Hydraulic System Main Pump Type: Variable displacement pump × 1 + Gear pump × 1 Travel Hydraulic Motor Type: 2-speed piston hydraulic motor Swing Hydraulic Motor Type: Piston hydraulic motor Fluid Capacities Fuel Tank: 100 L Dimensions Overall Transport Length: 5510 mm Overall Transport Width: 1960 mm Overall Transport Height: 2540 mm Total Track Length: 2500 mm Track Shoe Width: 400 mm Minimum Ground Clearance: 320 mm Minimum Swing Radius of Front Working Device: 2370 mm Rear Swing Radius: 1060 mm Working Range Maximum Digging Radius: 6045 mm Maximum Digging Depth: 3580 mm Maximum Digging Height: 5560 mm Maximum Dumping Height: 3855 mm Maximum Vertical Digging Depth: 2990 mm Dozer Blade Width × Height: 1960 × 360 mm Dozer Blade Lift Height / Digging Depth: 450 / 375 mm
