久保田 KX 135

# KUBOTA KX135 Crawler Excavator Specifications Model: KUBOTA KX135 Operating Weight: 3590 kg Bucket Capacity: 0.11 m³ Transport Dimensions (L×W×H): 4665 × 1700 × 2440 mm Track Shoe Width: 400 mm Travel Speed (High/Low): 5.5 / 3.5 km/h Swing Speed: 10 rpm Max Digging Depth: 3135 mm Max Digging Radius: 5265 mm Max Dumping Height: 3320 mm Max Digging Height: 4730 mm Ground Clearance: 290 mm ## Engine Engine Model: Kubota D1703-M-ES07 Rated Net Power: 21.0 kW / 2250 rpm Max Torque: 101 N·m /1600 rpm Displacement: 1647 cc Fuel Tank Capacity: 40 L ## Hydraulic System Main Pump Flow: 158 L/min Hydraulic system: Piston hydraulic motor for swing & travel
