沃尔沃 EC 460 D

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours:24 hours, holidays and Sundays Contact: Lily Whatsapp: +86 13696501072 Mobile:+86 17756597429 Wechat:17756597429 Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.

Volvo EC460BLC Excavator Parameter Configuration specification The working weight of the whole machine (kg) is 44500 Bucket capacity (m³) 1.8-3.73 Boom length (mm) 7000 Stick length (mm) 3350 Place of origin: Shanghai, China Tonnage (tons) 46 Joint ventures/imports Power: Traditional power Bucket backhoe Joint ventures/imports Power: Traditional power performance Slewing speed (rpm) 8.5 Travel speed (km/h) 2.9/4.8 Climbing ability (%) 70 Grounding specific pressure (Kpa) 77.5 Bucket digging force (kN) 253.0 (standard) / 276.5 (afterburner) Bucket digging force (kN) 195.1 (standard) / 213.8 (afterburner) dynamical system Engine model Volvo D12D Rated power (kw/rpm) 245/1800 Displacement (L) 12.1 Number of cylinders (pcs) 6 Bore × stroke (mm) 131×150 Cooling method: Water cooling Maximum torque in working form: 1720N.m/1350rpm Hydraulic system Main pump type variable axial piston pump × 2 gear pump The maximum flow rate of the main pump (l/min) is 345×2 31 Traveling hydraulic motor type variable axial piston motor Slewing hydraulic motor type axial plunger hydraulic motor Working hydraulic oil circuit (Mpa) 31.4/34.3 Traveling hydraulic circuit (Mpa) 31.4 Slewing hydraulic circuit (Mpa) 24.5 Control Hydraulic Circuit (Mpa) 3.9 Boom cylinder - number × bore × stroke (mm) 2-165×1590 Bucket cylinder - number × bore × stroke (mm) 1-190×1850 Bucket cylinder - number × bore × stroke (mm) 1-165× 1335 Whether the hydraulic crushing pipeline is standard or not Oil capacity Fuel tank (L) 685 Hydraulic Tank (L) 270 Hydraulic System (L) 525 Engine oil change volume (L) 42 Coolant (L) 60 Body size Total length of transport (mm) 12070 Total width of transport (mm) 3340 Total height of transport (mm) 3650 The overall height of the cab (mm) is 3250 Counterweight ground clearance (mm) 1275 Track grounding length (mm) 4370 Total track length (mm) 5370 Track shoe width (mm) 600 Total track width (mm) 3340 Track gauge (mm) 2740 Minimum ground clearance (mm) 550 The minimum turning radius of the front working device (mm) is 5090 Rear end turning radius (mm) 3730 Scope of work Maximum excavation radius (mm) 12000 The maximum excavation radius of the shutdown surface (mm) is 11780 Maximum digging depth (mm) 7700 Maximum digging height (mm) 10970 Maximum unloading height (mm) 7650 Maximum vertical digging depth (mm) 6840 Maximum effective digging depth (mm) 7550
