山河智能 SWE 150 E
不含税价格
打印
信息
类别
履带挖掘机
品牌/型号
山河智能 SWE 150 E
生产年份
2023
使用小时
1045 小时
国家
中国
一般等级
1
2
3
4
5
马斯客 ID
B580DCA5
定价
选择币种
详细信息
内部库存编号
1
电源类型
柴油机
生产号/编号
1
先前车主有几个
1
最新检验记录
2025-10-14
底盘状态
good condition
发动机
Original
毛重
14800 公斤
发动机输出功率
84 kW (114 马力)
发动机制造商
ISUZU
注册编号
1
排放标准
第V阶段
料斗容积
0.60 m3
履带宽度
600 mm
最大速度
5.40 千米/小时
运输尺寸(长x宽x高)
7815 x 2600 x 2825 mm
原色
Blue
状态/质保
1 year
制造国
中国
成交条件
FCA, FOB, CIF, EXW
证书
EPA环境保护署, CE认证
附属装置
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET
TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET
CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL
Business hours:24 hours, holidays and Sundays
Contact: Lily
Whatsapp: +86 13696501072
Mobile:+86 17756597429
Wechat:17756597429
Packaging Details
1. Flat frame is more suitable for large construction equipment without disassembly.
2. Containers are the cheapest and fastest.
3. Bulk carriers are more suitable for large construction equipment.
4. Ro-ro shipment is fast and suitable for all kinds of machines.
You can choose any mode of transportation according to your needs.
配件
铲斗管路断裂阀->安全铲斗管路断裂阀-吊杆/起重机
铲斗管路断裂阀 ->安全铲斗管路断裂阀-铲斗/楦头
空调
发动机润滑油滤清器
铲斗
旋转信号灯
附加设备
操纵杆
标准挖土铲斗
其他信息
Parameter configuration of the SWE150E excavator from Sunward Intelligent
Specification
Power Traditional Power
Domestic manufacturer
Bucket backhoe
Tonnage (tons)15
The working weight of the entire machine (kg) is 14,800
Bucket capacity (m³)0.6
Performance
Rotational speed (rpm)11.1
Walking speed (km/h) : 5.4/3.3
Climbing ability (%) : 35°
The ground pressure (Kpa) is 36.8
Bucket digging force (kN)100
The digging force of the bucket arm (kN) is 72.5
Maximum traction force (kN)96
Power system
Engine model: ISUZU AA-4BG1TCG-04
Rated power (kw/rpm) : 84/2200
Displacement (L)4.329
The cooling method is water cooling
Working form: 4-cylinder, 4-stroke, water-cooled
Hydraulic system
The main pump types are two variable piston pumps
The maximum flow rate of the main pump (l/min) is 2×139
The main overflow set pressure (Mpa) is 31.4 / pressurized is 34.3
Oil capacity
Fuel tank (L)245
Hydraulic oil tank (L)150
Main body size
The total transportation length (mm) is 7815
The total transportation width (mm) is 2600
The total transportation height (mm) is 2825
The total height of the cab (mm) is 2825
The width of the vehicle (mm) is 2520
Track grounding length (mm) : 3000
The total length of the track (mm) is 3735
Track plate width (mm) : 600
Track gauge (mm)2000
Minimum ground clearance (mm)410
The ground clearance of the counterweight (mm) is 915
The minimum turning radius (mm) of the front working device is 2510
The rear end turning radius (mm) is 2350
Scope of work
Maximum excavation radius (mm) : 8355
The maximum excavation radius of the shutdown face (mm) is 8230
Maximum excavation depth (mm) : 5640
Maximum excavation height (mm) : 8630
Maximum unloading height (mm) : 6130
Maximum vertical excavation depth (mm) : 4540
