小松 PC 120

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours:24 hours, holidays and Sundays Contact: Lily Whatsapp: +86 17756597429 Mobile:+86 17756597429 Wechat:17756597429 Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.

Komatsu PC120-6 excavator parameter configuration specification The working weight of the whole machine (kg) is 12030 Bucket capacity (m³) 0.5 Stick length (mm) 2100 Tonnage (tons) 12 Joint ventures/imports Power: Traditional power Bucket backhoe Joint ventures/imports Power: Traditional power performance Grounding specific pressure (Kpa) 0.39kg/c㎡ Rotational speed (rpm) 11 Travel speed (km/h) 2.7-5.5 Climbing ability (%) 70/30° Bucket digging force (kN) 8800 Stick digging force (kN) 6300 dynamical system Engine model Komatsu SAA4D95LE-3 Rated power (kw/rpm) 64/2200 Displacement (L) 3.26 Cooling method: Water cooling Working type: direct injection, turbocharged, intercooled diesel engine Hydraulic system The maximum flow rate of the main pump (l/min) is 226L/min Working hydraulic oil circuit (Mpa) 325kg/c㎡ Traveling hydraulic circuit (Mpa) 355kg/c㎡ Rotary hydraulic circuit (Mpa) 295kg/c㎡ Control hydraulic circuit (Mpa) 30kg/c㎡ Whether the hydraulic crushing pipeline is standard or not Oil capacity Fuel tank (L) 247 Hydraulic Tank (L) 90 Engine oil change volume (L) 11 Coolant (L) 13.4 Body size Total length of transport (mm) 7599 Total height of transport (mm) 2175 Cab total height (mm) 2175 Counterweight ground clearance (mm) 855 Track grounding length (mm) 2880 Total track length (mm) 3610 Track shoe width (mm) 500 Track gauge (mm) 1990 Minimum ground clearance (mm) 400 Rear end turning radius (mm) 2110 Scope of work Maximum digging radius (mm) 8290 The maximum excavation radius of the stopping surface (mm) is 8170 Maximum digging depth (mm) 5520 Maximum digging height (mm) 8610 Maximum unloading height (mm) 6170 Maximum vertical digging depth (mm) 4940 Maximum effective digging depth (mm) 5315 There is no bulldozer shovel for lifting or pushing depth (mm).
