神钢建机 SK 380

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours:24 hours, holidays and Sundays Contact: Lily Whatsapp: +86 13696501072 Mobile:+86 17756597429 Wechat:17756597429 Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.

Parameter configuration of Kobelco SK380XD-10 excavator Specification Power Traditional Power Domestic manufacturer Bucket backhoe Tonnage (tons)38 The working weight of the entire machine (kg) is 38,500 Bucket width (mm) : 1740 Bucket capacity (m³)1.9 Boom length (mm) : 2600 The length of the boom (mm) is 6500 Performance Rotational speed (rpm)10 Walking speed (km/h)5.6/3.3 Climbing ability (%)70 (35°) Ground specific pressure (Kpa) : 72 Bucket digging force (kN)229 Bucket shaft digging force (kN)207 Maximum traction force (kN)331 Power system Engine model: Hino J08ETM-KSDL Rated power (kw/rpm)197/2100 Maximum torque (N.m) : 968/1600 The cooling method is water cooling The working mode is direct injection, four-stroke, turbocharged, with built-in intercooling Hydraulic system The main pump type is a double variable displacement axial piston pump + pilot gear pump Rotary hydraulic motor type: Axial piston pump motor (1 piece) Walking hydraulic motor type: Variable capacity axial piston motor (2 pieces) The main overflow set pressure (Mpa) is 34.3 Oil capacity Fuel tank (L)503 Hydraulic oil tank (L)245 Hydraulic System (L)410 Main body size The total transportation length (mm) is 11,380 The total transportation width (mm) is 3190 The total transportation height (mm) is 3710 The total height of the cab (mm) is 3230 The grounding length of the track (mm) is 4050 The total length of the track (mm) is 4980 Track plate width (mm) : 600 The total width of the tracks (mm) is 3190 Track gauge (mm) : 2590 Minimum ground clearance (mm) : 515 The ground clearance of the counterweight (mm) is 1210 The minimum turning radius (mm) of the front working device is 4460 Scope of work Maximum excavation radius (mm) : 10,610 The maximum excavation radius (mm) of the shutdown face is 10400 Maximum digging depth (mm)6840 Maximum excavation height (mm) : 10230 Maximum unloading height (mm) : 7070 The maximum vertical excavation depth (mm) is 5700
