神钢建机 SK 250 LC

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours:24 hours, holidays and Sundays Contact: Lily Whatsapp: +86 13696501072 Mobile:+86 17756597429 Wechat:17756597429 Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.

Kobelco SK250-10 excavator parameter configuration specification Power: Traditional power Joint ventures/imports Bucket backhoe Tonnage (tons) 25 The working weight of the whole machine (kg) is 25600 Bucket width (mm) 1250 Bucket capacity (m³) 1.1 performance Rotation speed (rpm) 10.8 Travel speed (km/h) 6.1/3.8 Climbing ability (%) 70% (35°) Bucket digging force (kN) 170 Maximum traction (kN) 245 dynamical system Engine model: Hino J05ETB-EDDK Rated power (kw/rpm) 137/2100 Maximum torque (N.m) 654/1600 Displacement (L) 5.123 Number of cylinders (units) 4 Bore × stroke (mm) 112×130 Hydraulic system Main pump type: double series variable displacement axial piston pump + pilot gear pump Traveling hydraulic motor type variable capacity axial piston motor Rotary hydraulic motor type axial piston pump motor Working hydraulic oil circuit (Mpa) 34.3/37. 8 Oil capacity Fuel tank (L) 403 Hydraulic Tank (L) 165 Hydraulic System (L) 273 Body size Total length of transport (mm) 10210 Total width of transport (mm) 2990 Total height of transport (mm) 3180 Cab total height (mm) 3040 Boarding width (mm) 2980 Track grounding length (mm) 3470 Total track length (mm) 4260 Track shoe width (mm) 600/800 Total track width (mm) 2990 Track gauge (mm) 2390 Minimum ground clearance (mm) 460 Counterweight ground clearance (mm) 1090 Rear end turning radius (mm) 3120 Scope of work Maximum digging radius (mm) 10310 The maximum excavation radius of the shutdown surface (mm) is 10140 Maximum digging depth (mm) 7000 Maximum digging height (mm) 9740 Maximum unloading height (mm) 6870 Maximum vertical digging depth (mm) 5990 Maximum effective digging depth (mm) 6520
