斗山 DX 300

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours,24 hours, holidays and Sundays Address: Shanghai City, China Contact: Nina Whatsapp: +86 18055199047 Mobile:+86 18055199047 Wechat:18055199047 Email: Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs

Basic Information Operating Weight: 30,215 kg Bucket Capacity: 1.45-1.6 m³ Power Type: Conventional Power Manufacturer: Joint Venture / Imported Bucket Type: Backhoe Ton Class: 30 tons Boom Length: 6,245 mm Arm Length: 3,100 mm Performance Parameters Swing Speed: 9.4 rpm Swing Torque: 11,760 N·m Travel Speed: 5.7/3.2 km/h Ground Pressure: 0.57 kg/cm² Bucket Digging Force: 183.3 kN Arm Digging Force: 128.4 kN Engine Parameters Engine Model: DL08 Rated Power: 159 kW / 1900 rpm Number of Cylinders: 6 Bore × Stroke: 108 × 309 mm Hydraulic System Parameters Main Pump Type: Variable Displacement Piston Pump Maximum Main Pump Flow: 2 × 248 L/min Fluid Capacities Fuel Tank: 500 L Hydraulic Oil Tank: 280 L Dimensions Total Transport Length: 10,615 mm Total Transport Width: 3,199 mm Total Transport Height: 3,515 mm Total Track Length: 4,940 mm Track Shoe Width: 600 mm Total Track Width: 3,200 mm Minimum Ground Clearance: 506 mm Counterweight Ground Clearance: 1,150 mm Rear Swing Radius: 3,188 mm Number of Track Rollers (per side): 9 Number of Top Rollers (per side): 2 Number of Track Shoes (per side): 48 Working Range Maximum Digging Radius: 10,702 mm Maximum Digging Radius at Ground Level: 10,506 mm Maximum Digging Depth: 7,275 mm Maximum Digging Height: 10,315 mm Maximum Dumping Height: 7,303 mm Maximum Vertical Digging Depth: 4,907 mm Maximum Effective Digging Depth: 6,455 mm
