类别
履带挖掘机
品牌/型号
斗山 DX 300
生产年份
2024
使用小时
600 小时
国家
中国
一般等级
1
2
3
4
5
马斯客 ID
830BAC40

定价

选择币种

详细信息

内部库存编号
1
电源类型
柴油机
生产号/编号
1
先前车主有几个
1
最新检验记录
2025-07-07
底盘状态
Good Condition
发动机
Original
毛重
30215 公斤
发动机输出功率
159 kW (216 马力)
发动机制造商
Original
注册编号
1
排放标准
第V阶段
料斗容积
1.60 m3
履带宽度
600 mm
辅助液压设备的输出量
248 l/min
最大速度
5.70 千米/小时
运输尺寸(长x宽x高)
10615 x 3199 x 3515 mm
原色
Original
铲斗/楦头长度
3100 mm
状态/质保
1 Year
制造国
韩国
成交条件
FCA, FOB, CIF, EXW
证书
EPA环境保护署, CE认证
附属装置
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours,24 hours, holidays and Sundays Address: Shanghai City, China Contact: Jason Whatsapp: +86 13675656717 Mobile:+86 13675656717 Wechat:13675656717 Email: Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.
配件
铲斗管路断裂阀->安全铲斗管路断裂阀-吊杆/起重机
铲斗管路断裂阀 ->安全铲斗管路断裂阀-铲斗/楦头
电线盒
空调
显示更多
其他信息
Parameter configuration of Doosan DX300LC-9C excavator Specification Power Traditional Power Joint venture/import by manufacturers Bucket backhoe Tonnage (tons)30 The overall working weight of the machine (kg) is 30,215 Bucket capacity (m³) : 1.45/1.6 Boom length (mm) : 6245 The length of the boom (mm) is 3100 Performance Rotational speed (rpm) : 9.4 Rotary torque (Nm)11760 Walking speed (km/h) 5.7/3.2 The ground pressure (Kpa) is 0.57 kg/cm ² Bucket digging force (kN) : 183.3 The digging force of the bucket arm (kN) is 128.4 Power system Engine model: DL08 Rated power (kw/rpm) 159/1,900 Number of cylinders (6 Cylinder diameter × stroke (mm)108 *309 Hydraulic system The main pump type is a variable piston pump The maximum flow rate of the main pump (l/min) is 2*248 Oil capacity Fuel tank (L)500 Hydraulic oil tank (L)280 Main body size Total transportation length (mm) : 10,615 The total transportation width (mm) is 3199 The total transportation height (mm) is 3,515 Total track length (mm) : 4,940 Track plate width (mm) : 600 Total width of the tracks (mm) : 3,200 Minimum ground clearance (mm) : 506 The ground clearance of the counterweight (mm) is 1,150 Rear end turning radius (mm) : 3,188 Number of idler wheels (single side) (units)9 Number of idler wheels (single side) (units)2 Number of track plates (single side) (pieces)48 Scope of work Maximum excavation radius (mm) : 10702 The maximum excavation radius of the shutdown face (mm) is 10506 Maximum excavation depth (mm) : 7275 Maximum excavation height (mm) : 10315 Maximum unloading height (mm) : 7303 Maximum vertical excavation depth (mm) : 4907 Maximum effective excavation depth (mm) : 6,455
