斗山 DX 300
不含税价格
打印
信息
类别
履带挖掘机
品牌/型号
斗山 DX 300
生产年份
2024
使用小时
600 小时
国家
中国
一般等级
1
2
3
4
5
马斯客 ID
830BAC40
定价
选择币种
详细信息
内部库存编号
1
电源类型
柴油机
生产号/编号
1
先前车主有几个
1
最新检验记录
2025-07-07
底盘状态
Good Condition
发动机
Original
毛重
30215 公斤
发动机输出功率
159 kW (216 马力)
发动机制造商
Original
注册编号
1
排放标准
第V阶段
料斗容积
1.60 m3
履带宽度
600 mm
辅助液压设备的输出量
248 l/min
最大速度
5.70 千米/小时
运输尺寸(长x宽x高)
10615 x 3199 x 3515 mm
原色
Original
铲斗/楦头长度
3100 mm
状态/质保
1 Year
制造国
韩国
成交条件
FCA, FOB, CIF, EXW
证书
EPA环境保护署, CE认证
附属装置
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL
Business hours,24 hours, holidays and Sundays
Address: Shanghai City, China
Contact: Jason
Whatsapp: +86 13675656717
Mobile:+86 13675656717
Wechat:13675656717
Email:
Packaging Details
1. Flat frame is more suitable for large construction equipment without disassembly.
2. Containers are the cheapest and fastest.
3. Bulk carriers are more suitable for large construction equipment.
4. Ro-ro shipment is fast and suitable for all kinds of machines.
You can choose any mode of transportation according to your needs.
配件
铲斗管路断裂阀->安全铲斗管路断裂阀-吊杆/起重机
铲斗管路断裂阀 ->安全铲斗管路断裂阀-铲斗/楦头
电线盒
空调
附加液压设备
发动机润滑油滤清器
铲斗
旋转信号灯
柴油加热器
操纵杆
标准挖土铲斗
电缆铲斗
开沟/归类铲斗
V形开沟铲斗
车厢防护装置->车厢防护装置/落物保护装置
其他信息
Parameter configuration of Doosan DX300LC-9C excavator
Specification
Power Traditional Power
Joint venture/import by manufacturers
Bucket backhoe
Tonnage (tons)30
The overall working weight of the machine (kg) is 30,215
Bucket capacity (m³) : 1.45/1.6
Boom length (mm) : 6245
The length of the boom (mm) is 3100
Performance
Rotational speed (rpm) : 9.4
Rotary torque (Nm)11760
Walking speed (km/h) 5.7/3.2
The ground pressure (Kpa) is 0.57 kg/cm ²
Bucket digging force (kN) : 183.3
The digging force of the bucket arm (kN) is 128.4
Power system
Engine model: DL08
Rated power (kw/rpm) 159/1,900
Number of cylinders (6
Cylinder diameter × stroke (mm)108 *309
Hydraulic system
The main pump type is a variable piston pump
The maximum flow rate of the main pump (l/min) is 2*248
Oil capacity
Fuel tank (L)500
Hydraulic oil tank (L)280
Main body size
Total transportation length (mm) : 10,615
The total transportation width (mm) is 3199
The total transportation height (mm) is 3,515
Total track length (mm) : 4,940
Track plate width (mm) : 600
Total width of the tracks (mm) : 3,200
Minimum ground clearance (mm) : 506
The ground clearance of the counterweight (mm) is 1,150
Rear end turning radius (mm) : 3,188
Number of idler wheels (single side) (units)9
Number of idler wheels (single side) (units)2
Number of track plates (single side) (pieces)48
Scope of work
Maximum excavation radius (mm) : 10702
The maximum excavation radius of the shutdown face (mm) is 10506
Maximum excavation depth (mm) : 7275
Maximum excavation height (mm) : 10315
Maximum unloading height (mm) : 7303
Maximum vertical excavation depth (mm) : 4907
Maximum effective excavation depth (mm) : 6,455
