卡特 349 D

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours,24 hours, holidays and Sundays Address: Shanghai City, China Contact: Nina Whatsapp: +86 18055199047 Mobile:+86 18055199047 Wechat:18055199047 Email: Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs

Overall Machine Specifications: Operating weight is 46,285 kg; bucket capacity ranges from 1.8 to 3.11 cubic meters; boom lengths are available in three options: 7,400 mm, 6,900 mm, and 6,550 mm; stick lengths come in three choices: 4,300 mm, 3,900 mm, and 3,350 mm. Travel Performance: Swing speed is 8.7 revolutions per minute; travel speed is 4.5 kilometers per hour. Engine Configuration: Engine model is Caterpillar Cat C13 ACERT; rated power is 283 kW per minute; displacement is 12.5 liters; bore × stroke is 130 mm × 157 mm; cooling method is water-cooled. Hydraulic System: Maximum main pump flow is 734 liters per minute; main relief setting pressure is 35 MPa; working hydraulic circuit pressure is 35 MPa; travel hydraulic circuit pressure is 35 MPa; swing hydraulic circuit pressure is 31.4 MPa; pilot circuit pressure is 4.11 MPa; pilot pump flow is 43 liters per minute; boom cylinder quantity × bore × stroke is 1 × 160 mm × 1,575 mm; stick cylinder quantity × bore × stroke is 1 × 190 mm × 1,778 mm; bucket cylinder quantity × bore × stroke is 1 × 160 mm × 1,356 mm. Fluid Capacities: Fuel tank capacity is 705 liters; hydraulic tank capacity is 243 liters; hydraulic system capacity is 570 liters; engine oil change quantity is 42 liters; coolant capacity is 35.5 liters. Dimension Details: Total transport length is 12,450 mm; total transport width is 3,640 mm; total transport height is 3,680 mm; overall cab height is 3,210 mm; total track length is 5,070 mm; track shoe width is 750 mm; total track width is 3,640 mm; track gauge is 2,740 mm; minimum ground clearance is 510 mm; rear swing radius is 3,770 mm.
