卡特 345 GC

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours:24 hours, holidays and Sundays Contact: Jason Whatsapp: +86 13675656717 Mobile:+86 13675656717 Wechat:13675656717 Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.

Parameter configuration of Caterpillar's new generation CAT345 GC hydraulic excavator Specification Power Traditional Power Imported by the manufacturer Bucket backhoe Tonnage (tons)43 The working weight of the entire machine (kg) is 42,200 Bucket capacity (m³)2.41 Boom length (mm)6900 Performance Rotational speed (rpm)8.27 Rotary torque (Nm)155 Power system Engine model: C9.3B Rated power (kw/rpm)258/1900 Displacement (L)9.3 Cylinder diameter × stroke (mm) : 115*149 Hydraulic system The maximum flow rate of the main pump (l/min) is 630 Working hydraulic circuit (Mpa)35 Walking hydraulic circuit (Mpa)35 Rotary hydraulic circuit (Mpa)28 Oil capacity Fuel tank (L)600 Hydraulic oil tank (L)423 Engine oil change volume (L)32 Coolant (L)410 Main body size The total length of transportation (mm) is 11620 The total transportation width (mm) is 3340 The total transportation height (mm) is 3230 The total length of the track (mm) is 5030 Track gauge (mm) : 2740 Minimum ground clearance (mm) : 520 The ground clearance of the counterweight (mm) is 1300 The center distance of the idler wheels (mm) is 4040 Rear end turning radius (mm)3530 Scope of work The maximum excavation radius (mm) of the shutdown face is 11,290 Maximum excavation depth (mm) : 7200 Maximum excavation height (mm) : 10,540 Maximum unloading height (mm) : 7210 Maximum vertical excavation depth (mm) : 5390
