卡特 340 D2 L

Key Specifications of Caterpillar 340D2L Excavator - Operating Weight: 38,900~41,500 kg - Bucket Capacity: 1.9 m³ - Engine Model: Cat C9 - Rated Power: 208 kW - Displacement: 8.8 L - Bore × Stroke: 112 mm × 149 mm - Swing Speed: 8.3 r/min - Travel Speed: 4.6 km/h - Gradeability: 70% - Bucket Digging Force: 210 kN - Stick Digging Force: 185 kN - Max Traction Force: 300 kN - Max Main Pump Flow: 281 L/min - Pilot Pump Flow: 40 L/min - Fuel Tank Capacity: 620 L - Hydraulic Tank Capacity: 620 L - Total Transport Length: 11,170 mm - Total Transport Width: 3,620 mm - Total Transport Height: 3,630 mm - Total Track Length: 5,060 mm - Track Shoe Width: 600 mm - Track Gauge: 2,920 mm - Minimum Ground Clearance: 742 mm - Rear Swing Radius: 3,490 mm - Max Digging Depth: 7,190 mm - Max Digging Height: 10,330 mm - Max Dumping Height: 7,000 mm
