卡特 329 D2L

Main Specifications of Caterpillar 329D2L Basic Information - Model: 329D2L - Operating Weight: 29,000 kg - Bucket Capacity: 1.54 m³ Engine - Model: Cat C7.1 - Rated Power: 158 kW (209 hp); Net Power: 151 kW (203 hp) - Rated Speed: 1,800 r/min - Total Displacement: 7.1 L Overall Dimensions - Length × Width × Height (Transport State): 10,360 mm × 3,330 mm × 3,040 mm - Total Track Length: 4,360 mm - Track Gauge: 2,390 mm - Minimum Ground Clearance: 470 mm - Rear Swing Radius: 3,080 mm Working Range - Maximum Digging Radius at Ground Level: 10,720 mm - Maximum Digging Depth: 7,290 mm - Maximum Digging Height: 10,040 mm - Maximum Vertical Digging Depth: 6,160 mm Hydraulic System - Maximum Flow of Main Pump: 240 × 2 L/min - Working Hydraulic Circuit Pressure: 35 MPa - Travel Hydraulic Circuit Pressure: 35 MPa - Swing Hydraulic Circuit Pressure: 27.5 MPa - Pilot Circuit Pressure: 3.92 MPa Fluid Capacities - Fuel Tank: 520 L - Hydraulic Oil Tank: 257 L - Engine Oil Change Capacity: 22 L - Coolant: 31 L
