卡特 323 D L

Hello, I'm Gavin, specializing in the sales of construction machinery. We have been working in this industry for decades and have four large machine storage yards in Shanghai. If you are interested in any machines, please feel free to contact me. WhatsApp/WeChat: 0086 18019214942

Overall machine parameters: Working weight: 23000kg Bucket capacity: 1.2m³ Lift arm length: 5700mm Pole arm length: 2900mm Power parameters: Engine model: C6.4 ACERT Rated power: 110kW/2000rpm Displacement: 6.4L Number of cylinders: 6 Cylinder diameter × stroke: 102×130mm Cooling method: Water cooling Performance parameters: Rotation speed: 11.5rpm Travel speed: 3.5/5.7km/h Grade climbing ability: 70% (35°) Bucket digging force: 140kN Pole arm digging force: 106kN Hydraulic system parameters: Main pump maximum flow rate: 205L/min Main overflow set pressure: 35MPa Working hydraulic oil circuit pressure: 35MPa Travel hydraulic circuit pressure: 35MPa Rotation hydraulic circuit pressure: 25MPa Pilot circuit pressure: 3.9MPa Oil capacity: Fuel tank: 410L Hydraulic oil tank: 120L Hydraulic system: 260L (including oil tank) Engine oil replacement volume: 30L Coolant: 25L Main body dimensions: Total transportation length: 9460mm Total transportation width: 3180mm Total transportation height: 3050mm Track ground length: 3650mm Total track length: 4455mm Track plate width: 600mm Track gauge: 2380mm Minimum ground clearance: 450mm Rear end rotation radius: 2940mm Working range: Maximum digging radius from the stop: 9850mm Maximum digging depth: 6710mm Maximum digging height: 9470mm Maximum unloading height: 6500mm Maximum vertical digging depth: 5860mm
