卡特 320 B L

Technical Specifications of Caterpillar 320BL Below are the technical specifications of the Caterpillar 320BL excavator: - Engine Model: Cat 3066T - Net Power: 128 hp (at 1,800 rpm) - Displacement: 389 cu in (6.37 L) - Bore: 4.1 in (104 mm) - Stroke: 5.2 in (132 mm) - Operating Weight: 42,769.7 lb (19,400 kg) - Bucket Capacity: Approximately 1.2 yd³ (0.92 m³) - Maximum Digging Depth: 18.71 ft (5,690 mm) - Maximum Ground Reach: 28.75 ft (8,763 mm) - Maximum Digging Height: 28.78 ft (8,772 mm) - Track Gauge: 7.81 ft (2,380 mm) - Track Shoe Width: 31.5 in (800 mm) - Track Ground Contact Length: 11.98 ft (3,652 mm) - Swing Speed: Approximately 10.5 r/min - Fuel Tank Capacity: 89.9 gal (340 L) - Hydraulic Pump Flow: 97.8 gal/min (370 L/min)
