阿斯泰克 11-3660

Description: Conveyor Frame: 24” Deep Lattice Frame Idlers: All standard idlers are CEMA B – 5” diameter 35 degree troughing idlers on 4’ spacing 20 degree idlers at feed point close spacing Flat steel return idlers on 10’ spacing Undercarriage: Manual telescoping pin lock Axle – single axle with single 11:00 – 22.5 tires on swivel wheel boxes Receiving Trough: 5’ 6” long with adjustable rubber flashing Belt Drive: Head end drive 750 TPH capacity (100 pcf material) Class I TA3203 Dodge shaft mount reducer w/backstop 20 Hp - 3/60/230-460 TEFC electric motor V-belt, motor mounts and guards 16” dia., 3/8” grooved head pulley 14” dia. steel wing tail pulley 12” Screw take-up Enginerebuilt: 0 Transmissionrebuilt: 0
