捷尔杰 E 600 JP

Manufacturer JLG Type E600JP Built in 2012 Features Working height max 20,51 m Platform height 18,51 m Lateral reach 13,70 m Lifting capacity 230 kg Platform dimensions LxW 1,83 x 0,76 m Swivel range +/- 175° Overhang 1,25 m Gradeability 30% Overall dimension LxWxH 10,10 x 2,41 x 2,54 m Transport Position LxH 8,15 x 3,15 m can be moved up to a working height of 20,50 m Wheel pressure max. 60kN Ground clearance 0,29 m Engine battery Weight 6.934 kg Specifics Rotatable work basket Jib/vertical Rotation angle -40°/+100° 4x4 White tires Differential lock cross trunk very Long work cycles possible pendulum axis
