Max. working height: 21.20 m, Max. working outreach (120 kg): 11.00 m, Turntable rotation: 360°, Aluminium basket 1400x700x1100 h mm with max. load capacity 200 Kg (2 operators), Basket rotation: 90°+90°, Petrol motor: Honda 9.6 kW, Max. grade limit in translation: 30%, Gross weight: 3000 kg, Outrigger footprint: 3500x3500 mm/4200x2500 mm, Transport dimensions: length 5850 mm – width 890 mm – height 1930 mm, Electro-hydraulic controls (Danfoss), Cable control, Lock valves on cylinders, Acoustic signal during translation, Motor start/stop control from the basket, Hand pump for emergency descent, Locks for safety belts on the basket, Outreach limiting device, Rubber crawler-tracks, Electric motor 220 V, Hour counter, Air/water plug, Electrical plug 220 V, Standard painting, CE Certificate, Use and maintenance handbook, exhibition machine显示更多
Bini Gru
Via Aldo Moro,62 40050 Castello D'Argile Bologna 意大利
