酒井 SW884ND

Description: Features & Benefits: 3,000 VPM – 10 IPF ... 4.55 MPH Several amplitude and frequency settings/combinations per drum at operator’s station Counter-rotating eccentric weights All vibration controls at instrumental panel Chamfered drum edges 180 seat rotation Heavy-duty hitch design Durable rubber isolator system for vibratory drums Independent drum vibration Great side and curb clearance Triple filtered spray system Dual drum hydrostatic drive Increased drum wear-resistance thanks to alloy with 20% increase in hardness Standard Safety Equipment ROPS Sakai proprietary emergency brake pedal which kills the engine and stops the machine instantly. 3 inch retractable seat belt 39 inches of visibility to the front and rear from the operators seat Low profile design for low center of gravity Operator deck guard rails Horn and backup alarm Electric parking brake w/ interlock Specifications DRUM Size (w x d) 79 X 55 ins | 2000 X 1370 mm OPERATING Weight 29,165 lbs | 13,230 kg OSCILLATION Frequency 2,800 vpm | 46.7 Hz Centrifugal Force 38,600 lbs | 172 kN Normal Amplitude 0.024″ | 0.60 mm VIBRATION Frequency 3,000 vpm | 50 Hz Centrifugal Force 35,585 lbs | 158 kN Nominal Amplitude 0.022 ” | 0.55 mm ENGINE Make & Model Cummins QSF 3.8 T4 Final Horsepower 130 HP | 97.0 kw ... 2,200 rpm BRAKING Systems Hydrostatic Service Brake + SAHR Parking Brake + Combined Footbrake OPTIONS Airconditioning: 0 Enginemake: CUMMINS Enginemodel: QSF3.8 Gps: 0 Heater: 0 Ropstype: Enclosed Basedrivespeed: 4.55 Enginerebuilt: 0 Articulating: 1 Transmissionrebuilt: 0
